The oil mist eliminator Nina is specially designed for higher airflow and works on all machine tools with a cabin volume up to 424 CF (12 m³).

The Nina effectively cleans the oil mist formed during the machining process and provides clean air into the workshop, as well as recycling almost all of your oil/coolant from the mist.

The Nina is suitable for all applications involving processes using oil, coolants or other lubricants. Even with tough applications such as grinding and machining of cast iron you can expect 99.95% particle free air. Read more about how this is possible under the Technology section.

See examples of how others have installed their Nina oil mist eliminator under ”Installation Images” further down on this page.

Applikation

Öljyn erottaminen jäähdytysnesteestä

Montering

På maskinen, På pelarstativ, På väggstativ

Max kabinstorlek

<12 m3

Luftflöde

1200m3/h

Enhet

Nina 1200

Applikation

Öljyn erottaminen jäähdytysnesteestä

Montering

På maskinen, På pelarstativ, På väggstativ

Max kabinstorlek

<12 m3

Luftflöde

1200m3/h

Driftförutsättningar

5-50°C

Elförsörjning

3-fas, 380-480V, 50/60Hz, 6A

Motoreffekt

1.5kW

Märkström

3.3A

Rotorns varvtal

6700 rpm

Längd

777 mm

Bredd

833 mm

Höjd

936 mm

Vikt

119 kg

Inloppsrör

Ø 200 mm

Ljudnivå

<70 db (A)

The oil mist eliminator Nina is specially designed for higher airflow and works on all machine tools with a cabin volume up to 424 CF (12 m³).

The Nina effectively cleans the oil mist formed during the machining process and provides clean air into the workshop, as well as recycling almost all of your oil/coolant from the mist.

The Nina is suitable for all applications involving processes using oil, coolants or other lubricants. Even with tough applications such as grinding and machining of cast iron you can expect 99.95% particle free air. Read more about how this is possible under the Technology section.

See examples of how others have installed their Nina oil mist eliminator under ”Installation Images” further down on this page.

Enhet

Nina 1200

Applikation

Öljyn erottaminen jäähdytysnesteestä

Montering

På maskinen, På pelarstativ, På väggstativ

Max kabinstorlek

<12 m3

Luftflöde

1200m3/h

Driftförutsättningar

5-50°C

Elförsörjning

3-fas, 380-480V, 50/60Hz, 6A

Motoreffekt

1.5kW

Märkström

3.3A

Rotorns varvtal

6700 rpm

Längd

777 mm

Bredd

833 mm

Höjd

936 mm

Vikt

119 kg

Inloppsrör

Ø 200 mm

Ljudnivå

<70 db (A)
